JACKS & PLUGS
70
Jack Series
(continued from previous page)
Environmental
Thermal Range: Commercial –-
55?C to +85?C (non-operating), -
20?C to +65?C (operating);
Military –
-55?C to +85?C (non operating), -
40?C to +65?C
(operating)
Thermal Shocks: Commercial –
Per Mil-Std-202, method 107;
Per Mil-Std-202, method 106;
Military — 0% to 95% operating
and non-operating
Salt Spray: Commercial –
Per Mil-Std-202, method 101;
Military – Per Mil-Std-202,
method 101 (48 hours)
Moisture Resistance: Military –
Per Mil-Std-202, method 106
(240 hours)
Materials
Frame: Steel, nickel plated
Springs: Copper alloy
Contacts: Welded, crossbar, gold
plated
Military – Per Mil-Std-202,
method 107
Humidity: Commercial –
Ordering Information
Typical
Part No.
Conductors
Description
Mating Plug
Notes
Phono Jacks
3501FP
3501FR
3514PC
3517PC
BPJR**
BPJR**AU
BPJF**
BPJF**AU
BPJJ**
BPJJ**AU
2
2
2
2
2
2
2
2
2
2
single open
single open
single open
single open
single open
single open
single open
single open
single open
single open
3502A
3502A
3502A
3502A
3502A
3502A
3502A
3502A
3502A
3502A
Front mounting
Rear mounting
Right angle, PC mount
Right angle, PC mount
Rear mounting, colored insulators
Same as above, with gold-plating
Front mounting, colored insulators
Same as above, with gold-plating
Feed through mount
Same as above, with gold-plating
Phone Extension Jacks
3503
2
single open
3502A
TT or Bantam Jacks
TT34B
TT34BNY
WTT34B
3
3
3
double closed
double closed
double closed
TT253NC
TT253NC Nickel-plated frame, fanned terminals
TT253NC Wire-wrap terminals
MT 1/4" Jacks
MT334B
3
double closed
482NC
WMT334B
YMT334BN
3
3
double closed
double closed
482NC
482NC
Wire-wrap terminals
Nickel-plated frame, fanned terminals
** To designate color of insulator, use: 01– Black, 02 – Red, 03 – White, 04 – Yellow, 05 - Blue, 06 - Green
See Pages 80-82 for Mechanical Drawings
